Digital Pressure Gauge, Master
Model: PRD-700
Penerangan ：
- Supports multiple pressure types (gauge, absolute, differential, compound) with ranges up to 2500 bar and accuracy options from 0.2% to 0.01%.
- Utilizes the same premium sensors as the UK brand “Ashford Instrumentation”.
- Features a backlit LCD with six-digit, and data logging for up to 1600 records.
◼️ Fig.2: Differential Pressure
- Jaminan Perkhidmatan After-Sales / Waranti Berkualiti / Tinggi / Tinggi Tinggi
- Produk akan disesuaikan dengan keperluan anda, jadi imej produk adalah untuk rujukan.
- Baca lebih lanjut: 7 langkah untuk memilih tolok tekanan
Muat turun fail
Spesifikasi produk
左右尚有資訊
| Lokasi sambungan | Gunung bawah |
|---|---|
| Saiz nominal | 4.5" |
| Julat skala | 0 ... 10 mbar to 2500 bar, or other equivalent units of pressure, vacuum or compound |
| Unit tekanan | kPa, psi, kg/cm², mbar, MPa, mmH₂O, mmHg, inH₂O, Torr |
| Ketepatan | ±0.2% F.S., ±0.1% F.S., ±0.05% F.S., ±0.025% F.S., ±0.01% F.S. |
| Overpressure load | 120% F.S. |
| Sambungan proses | 316 SS 1/4, M20x1.5 G, NPT, M |
| Kes/cincin | Aluminum alloy |
| Tetingkap | Plastic |
| Diafragma | 316L ss |
| Paparan | 6 digits LCD, switchable backlight button |
| Masa tindak balas | 3 times/sec |
| Multifunction | Temperature display. Percentage bars indication for visual reference. Zero function. Peak function |
| Data Logging | 40 files, 40 data per file, 1600 records in total |
| Komunikasi | RS232 (Do not use the RS-232 connector in a hazardous area) |
| Bekalan kuasa | 7.4V rechargeable lithium battery, 110/220V external power adapter |
| Suhu ambien | -20 ... 60 ℃ |
| Suhu sederhana | 0 ... 50 ℃ |
| Temperature Compensated | 0 ... 50 ℃ |
| Berat | 0.7kg |
| Aksesori (pilihan) | Rubber protector, carrying case, tube for DP models |
| Explosion-proof | Certification approved (Certificate#.: Exia II CT4Ga) |
Imej produk sebenar
Digital pressure gauge backlit LCD with six-digit
Digital pressure gauge with replaceable lithium battery
Digital pressure gauge with charger and protective box
