Tolok tekanan digital, paparan LCD
Model: MXB
Penerangan ：
- Bar graph display can prevent overpressure
- Data logger helps record the highest and lowest peak values effectively
- Same material as PCE Deutschland GmbH
- Jaminan Perkhidmatan After-Sales / Waranti Berkualiti / Tinggi / Tinggi Tinggi
- Produk akan disesuaikan dengan keperluan anda, jadi imej produk adalah untuk rujukan.
- Baca lebih lanjut: 7 langkah untuk memilih tolok tekanan
Muat turun fail
Spesifikasi produk
左右尚有資訊
| Lokasi sambungan | Bottom mount, back mount, with/without flange, bottom mount with cooling element |
|---|---|
| Saiz nominal | 2.5", 3", 4" |
| Ketepatan | ±0.075% URL (standard), ±0.05% URL |
| Julat skala | 0 ... 5 kPa to 0 ... 100 MPa, or other equivalent units of pressure, vacuum or compound |
| Measuring medium | Liquid, gas, or steam flow as well as liquid level, density and pressure |
| Unit tekanan | MPa, kg/cm2, bar, psi, mmH2O, kPa, Pa, inWC, mbar, mH2O, inHg, mmHg, Torr (Up to 8 units can be switched, if not specified, the engineer will select it according to the pressure range) |
| Ketepatan | ±0.4% F.S. (standard), ±0.2% F.S. |
| Sambungan proses | 304 SS PT: 1/4", 1/2" G: 1/8", 1/4", 3/8", 1/2", 7/8" NPT: 1/4", 1/2" M: 12*1.5, 10*1.0, 10*1.5, 14*1.5, 20*1.5 |
| Kes/cincin | 304 ss |
| Panel | Akrilik |
| Diafragma | 316 ss |
| Suhu sederhana | -35°C ... 60°C |
| Paparan | 5.5 digits LCD, switchable backlight button |
| Masa tindak balas | 18 kali/saat |
| Bekalan kuasa | 2.5" bottom mount, 3": AAA battery*3 2.5" back mount, back mount with flange: AAA battery*4 4": AA battery*3 Optional external power supply: DC24V, DC5V, or with other transformers such as AC110V. You need to open the top cover to replace the battery of 2.5" back mount type. |
| Protection level | IP40 |
Paparan produk
Imej produk sebenar
2.5" Digital Pressure Gauge with Water-proof Connector
4" Digital LCD Display Pressure Instrument Bottom Mount
1/4" Male, Digital Pressure Instrument with VCR Fittings
